Stainless Steel 321 Pipes Manufacturer, Supplier and Exporter in Kuala lumpur, Malaysia

Maria Pipes and Tubes stands out as a top manufacturer and supplier of Stainless Steel 321 Pipes, proudly based in Kuala Lumpur, Malaysia. These pipes are specifically crafted for high-temperature and corrosive settings, featuring titanium stabilization that provides remarkable resistance to intergranular corrosion post-welding. At Maria, we blend precision engineering with rigorous quality standards to ensure our products align with international specifications like ASTM and ASME. Our SS 321 pipes are perfect for sectors such as aerospace, chemical processing, and heat exchangers. With streamlined logistics and a customer-first approach, we deliver reliable, high-performance piping solutions throughout Malaysia and Southeast Asia.

SS 321 Schedule 40 Pipe Price List in Kuala lumpur, Stainless Steel S32100 Pipes Supplier in Kuala lumpur, SS 321 Pipes Supplier in Malaysia, ASTM A312 Stainless Steel 321 Pipe Exporter in George town, AISI 321 Pipes Exporter in Kuantan, 1 inch SS 321 Pipe Price in Ipoh, SS 321 Pipe Weight Chart, SS 321 Schedule 20 Pipe Thickness, 321 Austenitic Stainless Steel Pipe Supplier in Malaysia

Stainless Steel 321 Pipes from Maria are crafted using an austenitic stainless steel alloy that’s stabilized with titanium, which has a carbon content at least five times lower. The typical chemical makeup includes 17–19% chromium, 9–12% nickel, and ≤0.08% carbon. The addition of titanium helps prevent carbide precipitation during welding, ensuring corrosion resistance in heat-affected areas. These pipes boast a tensile strength ranging from 515 to 750 MPa and a yield strength of about 205 MPa. SS 321 maintains its structural integrity even at high temperatures and resists oxidation and scaling, making it suitable for continuous service up to 900°C (1650°F).

Stainless Steel 321 Pipes Specification

Pipe Standard	ASTM A312 ASME SA312 / ASTM A358 ASME SA358
Pipe Dimension	ANSI/ASME B36.19M, ANSI/ASME B36.10M
Pipe Sizes	1 / 2″ NB – 24″ NB
Pipe Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Steel Pipe Manufacturing Process	Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Stainless Steel Pipe Shapes	Hydraulic, Round, Rectangle, Square, Hex, Honed
Stainless Steel Pipe Schedule	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Pipe Ends	Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Value Added Services	Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing

Stainless Steel 321 Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	N	Ni	Ti
SS 321	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 – 19.00	0.10 max	9.00 – 12.00	5(C+N) – 0.70 max

SS 321 Pipes Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1457 °C (2650 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

321 Stainless Steel Pipes Exporter in Malaysia, SS UNS S32100 Pipes Exporter in Kuala lumpur, 321 Stainless Steel Pipe Manufacturer in George town, SUS 321 Pipes Price List in Malaysia, ASTM A312 Stainless Steel 321 Pipe Supplier in Kuantan, Stainless Steel 1.4541 Pipes in Ipoh

Why Choose Stainless Steel 321 Pipes from Maria Pipes and Tubes?

Choosing Stainless Steel 321 Pipes from Maria Pipes and Tubes offers corrosion resistance and excellent durability, ideal for harsh environments. Their pipes are precisely engineered for durability and reliability, conforming to stringent industry standards. Brydon offers solutions tailored to suit specific business requirements, backed by exceptional customer service. Furthermore, their commitment to quality ensures longevity and performance, making them a reliable choice for a variety of applications. Trust Brydon’s expertise in providing quality stainless steel for your needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 321 Pipes Supplier in Kuala lumpur, Malaysia

Maria Pipes and Tubes, one of the largest suppliers of Stainless Steel 321 Pipes in Kuala lumpur, Malaysia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 321 Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

SS UNS S32100 Pipes Exporter in Ipoh, SUS 317L Pipes Supplier in Kuala lumpur, 317L SS Pipes Manufacturer in George town, 317L Austenitic Stainless Steel Pipe Dealer in Kuala lumpur, Stainless Steel S32100 Pipes Manufacturer in Kuantan, SS 317L Pipe Supplier in Malaysia

Types of Stainless Steel 321 Pipes

Are Custom Sizes Available for Stainless Steel 321 Pipes?

Yes, we offer custom sizes for Stainless Steel 321 Pipes to meet your specific requirements. Our team at Maria Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@mariapipes.com.

ASME SA 312 TP321 Pipes Kuantan, Stainless Steel 321 Pipes Supplier in Malaysia, 321 Stainless Steel Pipes Exporter in George town, SS UNS S32100 Pipes Supplier in Kuala lumpur, SS 321 Schedule 20 Pipe Exporter in Ipoh

Stainless Steel 321 Pipes find extensive use in industries that demand resistance to heat and intergranular corrosion. They are particularly well-suited for aircraft exhaust systems, chemical processing equipment, thermal oxidizers, and refinery systems. Additionally, SS 321 pipes are frequently utilized in heat exchangers, furnace components, boiler tubes, and expansion joints where they are consistently exposed to high temperatures. Their stability and excellent weldability make them ideal for pressure vessels and piping in the power generation and petrochemical industries.
