Maria Pipes and Tubes, a well-respected manufacturer and supplier located in Kuala Lumpur, Malaysia, focuses on producing top-notch Aluminium Seamless Tubing. This tubing is celebrated for its impressive strength, lightweight nature, and remarkable resistance to corrosion. Crafted using cutting-edge seamless extrusion techniques, these tubes boast a consistent thickness, a smooth surface finish, and exceptional dimensional accuracy. Industries that demand durable and reliable tubing solutions, such as aerospace, automotive, marine, and construction, widely utilize Aluminium Seamless Tubing from Maria Pipes and Tubes, ensuring outstanding performance even in the toughest conditions.
The Aluminium Seamless Tubing is mainly made from high-purity aluminium or aluminium alloys, with added elements like magnesium, silicon, and copper to boost strength and durability. These tubes showcase excellent mechanical properties, including good tensile strength, high elongation, and superior resistance to both corrosion and oxidation. Thanks to their seamless design, they lack weld seams, which enhances their ability to withstand pressure and prevents leaks. Additionally, the tubing provides excellent thermal and electrical conductivity while remaining lightweight and flexible for a variety of applications.
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
ASTM B429 / ASME SB429 – Standard Specification for Aluminum-Alloy Extruded Structural Tube and Tube
EN AW-AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Round Tube
ISO AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Tubing
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| 5083 | 0.40 max | 0.40 max | 4.0 / 4.90 | 0.40 / 1.0 | 0.10 max | 0.25 max | 0.15 max | 0.05 / 0.25 | 0.05 max | Bal |
| 6061 | 0.7 | 0.4-0.8 | 0.8-1.2 | 0.15 | 0.15-0.4 | 0.25 | 0.15 | 0.15-0.35 | 0.005/0.15 | Remainder |
| 6068 | 0.50 max | 0.7 – 1.3 | 0.06-1.20 | 0.40-1.00 | 0.10 max | 0.20 max | 0.10 max | 0.25 max | 0.05 max | Bal |
| 7075 min | 2.10 | 1.20 | 5.10 | 0.18 | ||||||
| 7075 max | 0.50 | 0.40 | 2.90 | 0.30 | 2.00 | 6.10 | 0.20 | 0.28 | 0.05 |
| Alloy | Temper | UTS(Mpa) | % Elongation | Tensile Strength | Hardness Brinell | Proof Stress | Yield Strength (PSI) | Shear Strength (PSI) | Brinell Hardness | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||||||||
| 1100 | O | 75 | 110 | 20 | 25 | 29 | ||||||
| H12 | 95 | 130 | 5 | 6 | 7 | |||||||
| H14 | 110 | 145 | 3 | 4 | 5 | |||||||
| H16 | 130 | 165 | 2 | 3 | 4 | |||||||
| H18 | 150 | — | 2 | 2 | 3 | |||||||
| 5083 | 12 Min % | 275 – 350 MPa | 75 HB | 125 Min MPa | ||||||||
| 6061 | – | 45,000 | 12 | 40,000 | 31,000 | 95 | ||||||
| 6082 | 8 | 295 | 95 | – | 240 | – | – | |||||
| 7075 T6, T651 | 11 | 83-572 | 73- 503 | 150 | ||||||||
| 7075 T73, T7351 | 13 | 73-503 | 63-434 | NA | ||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Aluminium Seamless Tubing from Maria Pipes and Tubes guarantees exceptional quality and performance tailored to your specific needs. Our seamless tubing is crafted from high-grade aluminum alloys, ensuring superior strength and durability while minimizing the risk of leaks or weak points. We adhere to stringent manufacturing standards and quality control processes to deliver reliable products for various applications, including automotive, aerospace, and construction. Additionally, our dedicated team provides expert support and customized solutions, making Maria Pipes and Tubes your trusted partner for all your aluminium seamless tubing requirements.
Maria Pipes and Tubes, one of the largest suppliers of Aluminium Seamless Tubing in Kuala lumpur, Malaysia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Aluminium Seamless Tubing to meet your specific requirements. Our team at Maria Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@mariapipes.com.
| Grade | UNS | USA | Japan | France | ISO | WNR | EN | DIN | ISO | BS (OLD) |
| 1100 | A91100 | AA1100 | JIS A1100P | NF 1100 | Al 99.0 Cu. | – | – | – | – | – |
| 6082 | A96082 | AA6082 | – | – | – | 3.2315 | AW-6082 | AlMgSi1 | AlSi1MgMn | HE30 |
| 5083 | A95083 | 5083 | – | – | AlMg4,5Mn0,7 | 3.3547 | AW-AlMg4,5Mn0,7 | AlMg4,5Mn | – | – |
| 6061 | A96061 | AA6061 | – | – | – | 3.3211 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 |
| 7075 | A97075 | 7075 | 3.4365 | ENAW-AlZn5.5MgCu EN AW-7075 | AlZnMgCu1.5 | AlZn6MgCu | 7075 L95 L96, V95 |
In the aerospace sector, Aluminium Seamless Tubing is commonly used for hydraulic lines and structural components. In the automotive industry, it serves as fuel and brake lines, while in marine applications, it is utilized for corrosion-resistant piping systems. In construction, it finds its place in architectural frameworks, HVAC systems, and heat exchangers. Its resistance to corrosion makes it a perfect fit for the chemical and food processing industries. Plus, the tubing’s impressive strength-to-weight ratio and flexibility make it ideal for precision instrumentation, medical devices, and other high-performance engineering applications.
